HikVision DS-7204HGHI-E1 4 Channel Turbo HD DVR
- Model: DS-7204HGHI-E1
- Type: 4 Channel Turbo HD DVR
- Video Output: 1-Channel VGA output and 1-Channel HDMI output; simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
- Video Compression: H.264 & Dual-stream video compression
- Resolution: 1080p, 720p, WD1, 4CIF, VGA, CIF
- Video Recording:
- Main stream: 720p resolution non real-time recording
- Sub-stream: 4CIF/2CIF @ 6 fps, CIF/QVGA/QCIF @ 25/30 fps
- Bit Rate: 32 Kbps to 4 Mbps
- Audio Compression: G.711u
- Audio Input: 1 channel, RCA (2.0 Vp-p, 1 KΩ)
- Audio Output: 1 channel, RCA (Linear, 1 KΩ)
- Two-way Audio: Reuse the first audio input
- IP Video Input: Up to 4 channels, up to 1080p resolution
- Analog Video Input: 4 channels, BNC interface (1.0 Vp-p, 75 Ω)
- Turbo HD Input: 1080p25, 1080p30, 720p25, 720p30
- AHD Input: 1080p25, 1080p30, 720p25, 720p30
- HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
- CVBS Input: Support
- Synchronous Playback: 4 channels
- Network Interface: 1 RJ45 10M/100M self-adaptive Ethernet interface
- Network Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Remote Connections: 128
- SATA: 1 SATA interface, up to 6 TB capacity for each disk
- USB Interface: 2 × USB 2.0 (rear panel)
- Power Supply: 12 VDC
- Power Consumption: ≤ 12 W (without HDD)
- Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity: 10% to 90%
- Dimensions: 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
- Weight: ≤ 0.8 kg (1.8 lb)
